NVR 32CH POE HASTA 4 HDD
HIKVISION
SKU: 3205
S/ 1724.00
Comprar
HIKVISION
SKU: 3207
NVR 64CH 8SATA - 220V (2)
S/ 6130.00
Descripción
NVR 64CH 8SATA - 220V (2)
| Video and Audio | |
| Entrada de Video Ip | 16-64-ch |
| Incoming Bandwidth | 400 Mbps |
| Outgoing Bandwidth | 400 Mbps |
| HDMI 1 Output | 8K (7680 × 4320)/30 Hz, 4K (3840 × 2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz |
| HDMI 2 Output | 4K (3840 × 2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz *: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p. |
| VGA 1 Output | 1920 × 1080/60 Hz |
| VGA 2 Output | 1920 × 1080/60 Hz |
| Video Output Mode | HDMI 1 and VGA 1 provide simultaneous video output, and work as the main output; HDMI 2 and VGA 2 provide simultaneous video output, and work as the auxiliary output |
| CVBS Output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Salida de audio | 2-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) |
| Descodificación | |
| Formato de decodificación | H.265+/H.265/H.264+/H.264 |
| Resolución de grabación | 32 MP/24 MP/12 MP/8 MP/7 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Resolución de grabación | 16-ch |
| Decodificación | 2-ch@32 MP (30 fps) + 2-ch@8 MP (30 fps)/10-ch@8 MP (30 fps)/20-ch@4 MP (30 fps)/40-ch@1080p (30 fps) |
| Compresión de audio | G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM |
| Red | |
| Protocolo de red | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF(Version 2.2), OTAP |
| Interfaz de red | 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Camera Access Protocol | ONVIF(Version 2.5), RTSP |
| Auxiliary Interface | |
| Interfaz de serie | 1 RS-485 (full-duplex), 1 RS-232 |
| SATA | 8 SATA interfaces supporting hot-plug |
| eSATA | 1 eSATA interface |
| Capacidad | Up to 16 TB capacity for each disk |
| Alarma E/S | 16/9 |
| Interfaz USB | Front panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0 |
| Ctrl 12V | Controllable 12 VDC, 1 A power output for external alarm device; The power will be turned on when the alarm output is triggered. *: The Ctrl 12V power is controlled by alarm output 9. |
| DC 12V | 12 VDC, 1 A power output |
| General | |
| Fuente de alimentación | 100 to 240 VAC, 50 to 60Hz |
| Consumo | ≤ 50 W (without HDD) |
| Temperatura de trabajo | -10 °C to 55 °C (14 °F to 131 °F) |
| Condiciones de Humedad | 10% to 90% |
| Chassis | 2U chassis |
| Dimensión (W × D × H) | 445 × 465 × 93 mm ( 17.5"× 18.3" × 3.7") ≤ 10 kg (without HDD, 22 lb.) |
